AU5240Crystal Oscillator(XO)
  • Output Frequency Range:
    200KHz to 1GHz
  • Phase Noise:
    110fs rms jitter
  • Fixed/Programmable Freq:
    Fixed(Orderable by Customer)
  • LGA Package Type:
    3.2 x 2.5 mm2, 6-Pin
    5.0 x 3.2 mm2, 6-Pin
    7.0 x 5.0 mm2, 6-Pin
    2.5 x 2.0 mm2, 6-Pin
AU5240
Features

• Output formats: LVPECL, CML, HCSL, HCSL-LP and LVDS

• Stability options:+/-25ppm total stability (-40C to 85C);+/-50ppm total stability (-40C to 105C)    • Support 3.3V, 2.5V and 1.8V power supply operation

• Excellent PSRR Performance with integrated LDO: -85dBC

• Ultra low current consumption: 50mA

Applications

• 100G/200G/400G/800G Direct Detect or Coherent Optics

• MIMO/Microwave Wireless

• UHD-SDI broadcast video

• Test and measurement

• General purpose FPGA/ASIC clocking

Advantages

• Enabling next generation wireline and wireless applications with high frequency and ultra-low jitter performance

• Excellent PSRR performance provides system robustness and enables simple power supply filtering design

• Ultra low power to facilitate simple thermal management

• Pin compatible with industry standard package XO in either 6-Pin or 8-Pin packaged programmable oscillators to ensure easy adoption

• Short lead time: Samples quantity: <2 weeks; Production quantity: <8 weeks
