AU5424GBuffer
  • Frequency Range:
    Up to 200MHz
  • Phase Noise:
    <50fs additive jitter
  • Input/Output:
    1:4 LVCMOS buffer
  • Package Type:
    8-DFN
AU5424G
Features

• Ultra low propagation delay: <1.6 ns

• Ultra low Output-to-Output skew: <50 ps

• Ultra Low Device-to-Device Skew: <200ps

• Supply voltage: 3.3 V, 2.5 V, or 1.8 V; 3.3V tolerant input at all supply voltages

• Operating temperature range: -40°C to 105°C (-40°C to 125°C Auto Grade option available)


System Benefits

• High-End Audio/Video

• Low additive jitter and low output-to-output skew ideal for jitter/phase senstive applications

• Wide operation voltage for design compatibility

• Low power consumption ideal for portable and high density applications


Applications

• Wireless and Wired Infrastructure

• Networking and Data Communications

• Medical equipment

• Automation and test equipment
