AU5508IEEE 1588 Clock
  • Frequency Range:
    0.5 Hz-2.94912 GHz
  • Phase Noise:
    ~ 120 fs typ
  • Input / Output:
    Up to 12 Diff / 24 SE Outputs
  • Voltage:
    VDD 1.8V~3.3V / VDDFT 1.8
AU5508
Features

• Fully Flexible Output and Input Mux: High level of flexibility in output allocation for PLLs

• JESD204B/C Support for data converter clocks

• 1 PPS Input / Output Support with sub 20s lock time

• External EEPROM Support

• TDC Mode available on all input clocks to measure input delays with < 10 ps accuracy: 10 TDC Channels available (independent of the PLLs)

System Benefits

• Lower Phase noise to minimizing bit error rate in the system

• Better signal integrity helps designer ease implementation and project faster time to market

• Higher function integration reduce system BOM

Applications

• OTN/PTN

• BBU/RRU

• LAN Switch/Router

• Small Cell

• SyncE Ethernet
