• Low power HCSL (LP-HCSL) outputs with ZO = 85 Ω

• Flexible control via SMBus interface and hardware output-enable pins

• Low phase jitter: 40 fs – 50 fs typical, and 8 fs RMS after PCIe Gen6

  filter

• Additive phase jitter with DB2000Q filter ~10fs RMS (typical)

• Output to Output Skew < 50 ps

• 3.3 V power supply and hardware-controlled low power mode

• Micro server and Tower server

• Rack server

• Storage area network and host bus adapter card

• Network attached storage

• SSDs

• Fully compliant with Intel DB2000Q specifications, suitable for

  PCIe Gen1-6 or QP/UPI applications

• Equivalent with 85 Ω Terminations, saving power and board space,

  no termination

• Only 175 mA current consumption with all 20 outputs enabled at

  100 MHz, reducing overall system power consumption

• Spread spectrum compatible; tracks spreading input clock for

  reducing EMI and improving system signal integrity

• Compact QFN package and standard pin configuration accelerate

  product development cycle
